技术参数：

电压：AC200V~240V  50～60Hz

功率：3000W   灯泡：XQ3KW

灯泡寿命：1000个小时（600小时后灯泡开始光衰）

防护等级：IP44

特殊设计反光碗，产生最高亮度输出

X轴：540°，具有光敏纠错功能，能自动校正灯具归位。

X轴微调：5.4°微调，定位更准确。

Y轴微调：270°，具有光敏纠错功能，能自动校正灯具归位。

Y轴微调节器：5.4°微调，定位更准确，白光+CMY换色系统，

可组合出多种颜色。平行光输出，投射距离可达2KM，

光柱大小直径250mm

机体部有过压，过热，过载，短路保护。

外形尺寸：500×420×730mm

包装尺寸：570×470×840mm

控制信号：DMX-512内程序单台自走功能，

内程序多台主从同步功能控制信号复位功能，X轴Y轴反向。

Technical parameters:
Voltage: AC200V~240V 50 ~ 60Hz
Power: 3000W bulb: XQ3KW
Bulb life: 1000 hours (after 600 hours the bulb starts to fade)
Protection grade: IP44
Specially designed reflective bowl produces maximum brightness output
X axis: 540°, with photosensitive error correction function, can automatically adjust the position of lamps.
X-axis fine tuning: 5.4° fine tuning, more accurate positioning.
Y axis fine tuning: 270°, with photosensitive error correction function, can automatically adjust the position of lamps.
Y-axis microregulator: 5.4° fine tuning, more accurate positioning, white light +CMY color changing system,
Can be combined into a variety of colors. Parallel light output, projection distance up to 2KM,
The diameter of the light column is 250mm
Overpressure, overheat, overload, short circuit protection.
Overall dimension: 500×420×730mm
Package size: 570×470×840mm
Control signal: dmx-512 internal program single function,
Internal program multiple master slave synchronization function control signal reset function, X axis Y axis reverse.
