技术参数：

额定电压：AC100-240V 50/60Hz
额定功率：600W

光源系统：PHILIPS MSD Platinum 20 R 金卤杯泡
反光碗：灯杯一体
变焦范围：3°～40.7°
多点色温变化（2500K、3200K、7800K）;
三个颜色盘（每个色盘上有：6个色片+白光），三个颜色盘叠加可产生更加丰富的颜色，可实现颜色彩虹；
1个旋转图案盘，带有6个图案片（可插拨式）+白光，可实现自转、流水、抖动效果，图案轮可定位
1个固定图案盘，带有18个图案+白光
独立雾化效果；
机械线性调光0~100%；
快速频闪，多频闪方式选择，脉动、异步、同步、随机慢中快；
棱镜：1个自旋八棱镜/十六棱镜（任选一），可双向旋转；
1个六面梯度镜，可旋转；
棱镜与梯度镜可叠加；
动感轮效果，可与固定图案盘、旋转图案盘叠加。
角度：水平540°，精度2.11°/步，微调精度0.008°；垂直270°，精度1.05°/步，微调精度0.004°。
水平和垂直采用电光复位系统
控制和编程：18通道控制模式
通讯协议：标准DMX512协议，Art-net以太灯光控制协议和无线DMX512控制。
菜单显示：触摸液晶屏，中、英两种语言可随意切换，字体可倒转180°显示；任选触摸式和按键两种操作方式。
产品尺寸：440*310*680 MM

Technical parameters:
Rated voltage: ac100-240v 50/60hz
Rated power: 600W
Light source system: PHILIPS MSD Platinum 20 R metal halide cup foam
Reflective bowl: integrated light cup
Zoom range: 3° ~ 40.7°
Multi-point color temperature change (2500K, 3200K, 7800K);
Three color plates (there are 6 color plates + white light on each color plate), the three color plates can be superimposed to produce richer colors and realize color rainbow;
1 rotating pattern plate, with 6 patterns (pluggable) + white light, can achieve rotation, water, shaking effect, pattern wheel can be positioned
1 fixed pattern disc with 18 patterns + white light
Independent atomization effect;
Mechanical linear dimming 0~100%;
Fast stroboscopic, multi-stroboscopic mode selection, pulsating, asynchronous, synchronous, random slow medium fast;
Prism: 1 spin octave / 16 prism (optional), bidirectional rotation;
A six-sided gradient mirror, rotatable;
Prism and gradient mirror can be superimposed.
Dynamic wheel effect, can be superimposed with fixed pattern disc, rotating pattern disc.
Angle: horizontal 540°, accuracy 2.11°/ step, fine tuning accuracy 0.008°; Vertical 270°, accuracy 1.05°/ step, fine tuning accuracy 0.004°.
Electro-optical reset system is used horizontally and vertically
Control and programming: 18 channel control mode
Communication protocol: standard DMX512 protocol, art-net Ethernet light control protocol and wireless DMX512 control.
Menu display: touch the LCD screen, Chinese and English languages can be switched at will, font can be inverted 180° display; Optional touch and button operation.
Product size: 440*310*680 MM
